Features:

l  Simultaneously acquisition of 12 lead, full screen display of 12 channel ECG waveforms

l  10.2" color touch-screen, both push-button and touch operation.

l  Defibrillation protection and Pacemaker detection.

l  Sensitive filters of ADS, HUM, and EMG.

l  Automatic measurement, calculation, analysis, waveform freezing. Auto-analyze and auto-diagnostic can reduce doctor's burden and improve working efficiency.

l  Automatic adjustment of baseline for optimal recording.

l  Thermal printer with 216mm print paper, synchronization print.

l  Lead off & lack off paper detection function.

l  Built-in rechargeable Li-ion battery (14.8V/4000mAh), AC/DC power conversion.

l  Adapt to 100-240V, 50/60Hz AC power supply

l  Historical data and patient's information can be reviewed and printed.

l  Support USB flash disk, stored reports can be saved, opened, analyzed in PC.

l  The machine can store over 400 ECG reports inside.

l  Connect with PC via ECG workstation software by USB or RS232. LAN can be chosen.

l  Sleep mode to save energy and extend LCD life.

l  The device can record real-time 12 leads ECG waveform continually.

l  The remark includes: lead sign, sensitivity, paper speed, filter state, etc.

l  Portable design with hidden handle, convenient to carry.

l  7 level printing thick can be chosen.
